CONVEX MOBILE 201

ARC WELDING

SYNERGIC MULTIPROCESS INVERTER COMPACT EQUIPMENT

Powerful single phase welding power source in the size of just one wire feeder unit: this is the main peculiarity of CONVEX MOBILE 201.
Innovative multiprocess synergic equipment for welding in MIG/MAG, MMA and TIG with “Lift” mode.
Versatile, easy-to-carry and user friendly, CONVEX MOBILE 201 equipment are greatly appreciated, also thanks to their very high technological conception, anywhere high quality welding is required and are ideal for on-site works, maintenance jobs, car body repairs and light fabrication works.

Category:
To receive more information about CEA products
please fill out the form
  • CEA Welding is committed to protecting and respecting users’ privacy: the personal information collected is only used to administer the accounts and provide the requested products and services. Users may be contacts with suggestions on products, services or other content that we believe could be interesting for them. If you want to be contacted for this purpose, select one of the following contact modes:
  • In order to give you the requested content, we need to store and use your personal data. If you allow us to do this, please select the checkbox below.
  • You can unsubscribe at any moment. For further information about the execution of this procedure, consult our privacy policy and other recommendation regarding the protection and respect of privacy; read our Privacy policy.

SYNERGIC INVERTER COMPACT

  • PFC: Power Factor Correction foroptimizes the amount of energy consumption by allowing their use, at maximum power, on 16 a fuse mains.
  • Digital control of the welding parameters with synergic curves preset according to used type of material, gas and wire diameter
  • Ability to store personalized welding parameters up to 99 JOBS
  • “ Smart PROGRAM” key for quickly selecting any program
  • Feeding mechanism with 4 rolls of large diameter for a precise and constant wire driving
  • Double groove rolls replaceable without any tool
  • “Energy saving” function to operate the power source cooling fan and torch water cooling only when necessary
  • Excellent arc striking always precise and efficient
  • Ability to partially or totally lock the equipment with access key by password
  • Reduced energy consumption
  • Trouble shooting auto-diagnosis feature
  • Initial and final crater control
  • VRD – Voltage Reduction Device

VISION.ARC

vision.ARC is the innovative welding arc control developed by CEA granting a short arc extremely stable and precise in spite of any change of the external conditions. vision.ARC ensures outstanding performances, impossible to be obtained by traditional power sources.

TECHNICAL DATA     CONVEX MOBILE 201
MIG/MAG TIG MMA
Single phase input 50/60 Hz V +15%
-15%		 230
Input Power @ I2 Max kVA 6 4,6 7,1
Delayed Fuse (l eff) A 16 16 16
Power Factor / cos φ   0,95/0,99 0,95/0,99 0,95/0,99
Efficiency Degree   0,84
Open circuit voltage V 45 45 45
Current range A 10-200 5-200 10-200
Duty cycle at (40°C) A 100% 105 105 105
A 60% 140 140 140
A % 200(25%) 200(25%) 200(25%)
Wires Ø mm 0.6-1.2 — —
Coil Ø mm 300 — —
Standards   EN 60974-1 • EN 60974-5 • EN 60974-10
Protection Class IP 23S
Insulation Class   H
Dimensions  mm  650
 mm 300
 mm 388
Weight kg 20
