MAXIQ

Arc welding

MAXIQ

SOMETHING DIFFERENT IN THE WELDING MARKET

HYBRID SYNERGIC^RMIG-MAG INVERTER EQUIPMENT WITH SEPARATE WIRE FEEDER

These power sources represent the best choice in all industrial fields for any qualified applications, such as medium and large fabrication work, shipyards and steel erection.

MAXIQ

Great welding performance

MAXIQ represents the logic evolution of the conventional step adjustment MIG equipment. It’s realized with a modern inverter integrated into a sturdy metallic structure and it’s managed by a simple and innovative digital control which will always grant high Quality welding performances.

Simple and Strong

MAXIQ keeps the adjustment simplicity of the conventional MIG equipment. Using only two knobs to set Voltage and Wire Speed, it offers the pleasure to set welding parameters as wished; with MAXIQ you never need any pre-selected synergic programs for setting the parameters on your behalf.

Other characteristics

Two MIG/MAG welding modes: MANUAL and HYBRID SYNERGIC^R
All parameters digitally controlled directly from the wire feeder
“HYBRID SYNERGIC^R PRE SET” key for the best welding characteristic according to used type of material and wire
“Energy saving” to operate the power source cooling fan and torch water cooling only when necessary
Excellent arc striking
Final crater control
Burn-Back control
MAXIQ W is fitted with an integrated water cooling unit

Technical features

Hybrid Synergic ʀ

This control represents something absolutely innovative in the welding world. While keeping the welding equipment in manual adjustment, the HYBRID SYNERGIC^R – depending on the material and the diameter of the wire used – defines the best response in terms of starting and depositing of the wire throughout the welding cycle.

SMART LED ASSISTANT

In addition, a “smart LED” signal helps less skilled operators to set the most appropriate welding parameters.

vision.ARC

Thanks to vision.ARC, the electric arc is monitored continuously by the microprocessor which manages the welding process in real time: all the parameters are processed and modified by the control that digitally manages the short circuits of MIG-MAG, keeping the arc stable and precise despite any change of the external conditions. The welding process is always under control from arc striking, by Wire Start Control (WSC), to when the arc is interrupted by Burn-Back Control.

MF 4 and MF 4W wire feeder

The digital control of all parameters is located directly on the MF4 (air cooled) and MF4W wire feeders (water cooled).

4 rolls of large diameter
Double groove rolls replaceable without any tool
Wire spools up to 300 mm diameter
Inspection window in the spool cover

FSC - Fast Start Control

It is the innovative arc striking control that reduces drastically the ignition time. By this new technology it is possible to have a quick and perfect ignition at every start.

This is ideal for spot-welding and pre-assembly of components.

SPECIAL 4 STROKE

It is the special time-saving feature in any welding. Every welder who welds in 4-stroke can quickly prepare the workpiece to be welded by making a perfect weld point without changing any adjustments. By simply pressing the torch trigger for less than a second, you can use the 2-stroke function, even if the welder is set to 4-stroke. Maintaining the same settings, it is sufficient to press the torch trigger for more than a second and the welding equipment works automatically in 4-stroke.

SIMPLE AUTOMATION

CEA power sources are standard equipped with analogic-digital I/O. This allows to integrate very easily the power source into an automated welding equipment without any expensive and sophisticated external interfaces, usually necessarily supplied for robotics.

Available accessories

Discover all available accessories

Configurator

Wire Feeder MF 4

Wire Feeder MF 4 Hybrid Synergic 4 rolls (Ø: 1,0 / 1,2) Air cooled version

Wire Feeder MF 4 W

Wire Feeder MF 4 W Hybrid Synergic 4 rolls (Ø: 1,0 / 1,2) Water cooled version

WK 4 standard wheels kit

WK 4 standard wheels kit for MF 4, MF4 yard and QF 7 W PRO DRIVE feeder

WK 2 extra-large wheel kit

HK 1 Hanging Kit

HK 1 Hanging Kit for wire feeder

INTERCONNECTING CABLE 1,2 m AIR

1,2 m Air cooled Interconnecting cable Power source-Wire feeder

INTERCONNECTING CABLE 4 m AIR

4 m Air cooled Interconnecting cable Power source-Wire feeder

INTERCONNECTING CABLE 10 m AIR

10 m Air cooled Interconnecting cable Power source-Wire feeder

INTERCONNECTING CABLE 1,2 m WATER

1,2 m Water cooled Interconnecting cable Power source-Wire feeder

INTERCONNECTING CABLE 4 m WATER

4 m Water cooled Interconnecting cable Power source-Wire feeder

INTERCONNECTING CABLE 10 m WATER

10 m Water cooled Interconnecting cable Power source-Wire feeder

CEA Torch CX 353/4

CEA Torch CX 353/4 4 m wire Ø 0.8÷1.2 CO2 340A @60% / Mix 290A @60%

CEA Torch CX 451/4

CEA Torch CX 451/4 4 m wire Ø 0.8÷1.6 CO2 400A @60% / Mix 300A @60%

CEA Torch CXH 302/4

CEA Torch CXH 302/4 4 m wire Ø 0.8÷1.2 water cooled CO2 300A @100% / Mix 250A @100%

CEA Torch CXH 402/4

CEA Torch CXH 402/4 4 m wire Ø 0.8÷1.6 water cooled CO2 500A @100% / Mix 450A @100%

CEA Torch CXH 302/4 Up/Down-17p

CEA Torch CXH 302/4 Up/Down-17p 4m – wire: Ø 0,8÷1.2 – CO2 300A @100% / Mix 250A @100%

CEA Torch CX 353/4 Up/Down-17p

CEA Torch CX 353/4 Up/Down-17p 4m – wire: Ø 0,8÷1.2 – CO2 340A @60% / Mix 290A @60%

CEA Torch CXH 402/4 Up/Down-17p

CEA Torch CXH 402/4 Up/Down-17p 4m – wire: Ø 0,8÷1.6 – CO2 500A @ 100% / Mix 450A @100%

CEA Digitorch DXH 302/4-17p

CEA Digitorch DXH 302/4-17p 4m – wire: Ø 0,8÷1.2 – CO2 300A @100% / Mix 250A @100%

CEA Digitorch DX 353/4-17p

CEA Digitorch DX 353/4-17p 4m – wire: Ø 0,8÷1.2 – CO2 340A @60% / Mix 290A @60%

CEA Digitorch DXH 402/4-17p

CEA Digitorch DXH 402/4-17p 4m – wire: Ø 0,8÷1.6 – CO2 500A @100% / Mix 450A @100%

Push Pull Torch PP 401 D 8 m 24 V water cooled

Push Pull Torch PP 401 D 8 m 24 V - wire Ø 0,8÷1,2 water cooled (to be ordered with 031107 or 031113)

Push Pull Synchronizer 24/42V

Push Pull Synchronizer PC Board KIT 24 / 42 V (to be ordered with the Push pull torch)

50 mm² / 4 m Ground cable with clamp

70 mm² / 4 m Ground cable with clamp

Cea CL-1100

Cea CL-1100 cooling liquid – 5 l Tank

RC 178

RC 178 remote control with 5 m cable

Gallery

MaxiQ at work: configurations and most common uses

Datasheet

MAXIQ: Technical features

TECHNICAL DATA			MAXI-Q
			400	400 W	500	500 W
Three phase input 50/60 Hz	V	+20% -20%	400
Input Power @ I₂ Max	kVA		19	19,5	25,5	26
Delayed Fuse (l eff)	A		25	25	32	32
Power Factor / cos φ			0,80/0,99		0,87/0,99
Efficiency Degree			0,86		0,86
Open circuit voltage	V		62
Current range	A		10-400		10-500
Duty cycle at (40°C)	A 100%		300		390
	A 60%		350		430
	A 35%		400		500
Wires	Ø mm		0,6-1,6
Standards			EN 60974-1 • EN 60974-5 • EN 60974-10

Protection Class	IP		23S
Dimensions (LxWxH)	mm		1040 x 495 x 950
Weight	kg		66	78	68	80
